Teradek Bolt 1000

Deluxe Kit Wireless Receiver Set

Teradek

Product Highlights

  • Uncompressed Video & Audio Transmission
  • Supports Resolutions up to 1080p60
  • 1000′ Distance (line of sight) with <1 ms Latency
  • Dynamic Frequency Selection
  • 3G-SDI/HDMI Inputs and Outputs
Rentex No. IMGW100 | Mfr No. 10-0965-1G

The Bolt 1000 Deluxe Kit has everything you need to get up and running with Bolt. It comes with a Bolt 1000 Transmitter and Receiver set, an antenna array to improve reception, a Dual Battery Mount plate for the Receiver, that can all fit with the included SKB Utility Case.



  • (1) TERADEK BOLT 1000 TRANSMITTER
  • (1) TERADEK BOLT 1000 RECEIVER
  • (2) TERADEK AC ADAPTER
  • (1) BOLT TX BATTERY PLATE
  • (2) BOLT TX BATTERY
  • (1) BOLT TX BATTERY CHARGER
  • (1) 11″ Articulating Arm
  • (7) Wireless Antennas (2dBi 2.4/5.8GHz)
  • (2) SDI Cable – Coiled
  • (2) HDMI Cable
  • (1) 2-pin Connector to PowerTap
  • (1) Hot Shoe Adapter (1/4″-20)
  • (2) CABLE:USB A(M) TO MINI-B

Transmitter

Video Input  1 x 3G/HD/SD-SDI, BNC (75 Ohms)
1 x HDMI

Video Output 1 x 3G/HD/SD-SDI, BNC (75 Ohms), loop-through out

Channels Number of 20 MHz DFS Channels: 24
(200 MHz channels cannot utilize interlaced, PsF, or 1080p 60/50)
Number of 40 MHz DFS Channels: 11 (USA)

Delay <0.001 sec

RF Power 17 dBm EIRP (with two 2 dBi TX antennas)

Audio 48 kHz, 24-bit PCM

Mounting 1/4″-20 threaded mounting holes

Dimensions 0.9 x 2.6 x 4.0″

Weight 8 oz / 226.8 g

Power Volts: 7 to 28 VDC
Consumption: 7.5 W
Connector: 2-pin LEMO

Receiver

Video Output 1 x 3G/HD/SD-SDI, BNC (75 Ohms)
1 x HDMI
1 x Micro-USB 3.0

Delay <0.001 sec

RF Power 17 dBm EIRP (with one 2 dBi TX antenna)

Audio 48 kHz 24-bit PCM

Dimensions 5.5 x 3.5 x 0.9″

Weight 13.3 oz / 376 g
