Barco ImagePRO-3G

All-In-One Signal Processor

Barco

Product Highlights

  • Switching, Transcoding & Scan Conversion
  • 3G/HD/SD-SDI Input & Output
  • Supports Resolutions Up to 1080p & WUXGA
  • NTSC & PAL (Plus SECAM Decoding)
  • I/O: RGB & DVI Computer Video, Component/Composite/S-Video
Rentex No. IPIPRO3G | Mfr No. R9004676

The Barco ImagePRO-3G All-In-One Signal Processor is a four-input, six-output seamless switcher, a scaler that handles resolutions from 480-line NTSC up to 1080p HDTV and WUXGA (1920 x 1200), a scan converter that decodes PAL, SECAM & NTSC and encodes NTSC & PAL, an aspect ratio converter, a transcoder, and a de-interlacer. High-performance scaling is handled by Barco’s proprietary Athena technology, a 10-bit image-processing technology that uses horizontal and vertical filtering techniques to provide crisp, clean images for both up- and down-conversion.

The 1080p HDTV format becomes possible thanks to the ImagePRO-3G’s 3G/HD/SD-SDI input and output, which, of course, support SMPTE 424M for 3 Gb/s transfer. Besides this SDI input/output pair, there is also an array of connections for RGB (computer) video sources as well as component, composite, and S-Video; the three input channels for these all feature loop-through. True blackburst genlock input is provided so you can lock all output formats to the blackburst signal, timing together the output of multiple units and eliminating frame-rate conversion problems that would otherwise result in motion artifacts.

The ImagePRO-3G also performs flexible pan & zoom for viewing fine detail in areas of a video frame. Extensive front-panel controls allow you to select sources, adjust setup parameters, store and recall logos, and access menu functions – the menu is viewable on the front panel’s electro-luminescent display.

  • (1) BARCO ImagePRO-3G
  • (2) VGA(F) to DVI-I(M) ADAPTER
  • (2) VGA(M) to 5-WIRE(BNC) BREAKOUT
  • (2) 6′ VGA (M-M) CABLE
  • (2) 6′ DVI-I (M-M) CABLE
  • (1) MANUAL
  • (1) POWER CORD/POWER SUPPLY
Video inputs
Number of inputs 4
Universal inputs
  • (3) high bandwidth video channels support RGBHV/RGBS/RGsB computer video, component video (SD or HDTV), S-video, or Composite video
  • Connectors: Input 2 on 15-pin HD connectors with buffered loop-through. Input 3 on five BNC connectors with buffered loopthrough
  • Input 1 on DVI-I connector supports both universal analog and DVI input with loop-through
  • (1) 3G/HD/SD SDI on a BNC connector.
Input resolution range VGA (640×480), SVGA(800×600), XGA(1024×768), SXGA(1280×1204), UXGA(1600×1200), WUXGA (1920×1200), HDTV 480p, 720p, 1080p, 1080i, 875 RS-343, 525 RS-170
Standard resolution video input NTSC, PAL or SECAM
Horizontal frequency 15 kHz to 120 kHz
Vertical frequency 25 Hz to 120 Hz
Input termination 75 Ohm
Input sync Sync-on-Video, Separate C or H/V
External sync (Genlock) Input: Blackburst, Computer H/V Sync or C-sync.
Connectors BNC
Video outputs
Number of outputs 6
Connectors
  • RGB or component video (SD or HDTV) on HD-15
  • RGB or component video (SD or HDTV) or composite video on five BNC
  • Composite video on BNC
  • S-video on 4-pin mini-DIN connector
  • 3G/HD/SD SDI on a BNC connector
  • DVI output on DVI-D connector
Standard resolution video output NTSC, PAL
High resolution output supported VGA (640×480), SVGA(800×600), XGA(1024×768), SXGA(1280×1204), UXGA(1600×1200), WUXGA (1920×1200). For Plasma Displays 1280×768, 1365×768, 1365×1024. HDTV 480p, 720p, 1080p, 1080i. 875 RS-343, 525 RS-170. User definable video output formats supported.
Sync RGBHV, RGBS, RGsB, TTL level, Polarity selectable, HDTV. Tri-level Sync supported. 75 ohm Output Impedance.
Other
Remote control Ethernet connection (with TCP/IP) or RS-232 serial port for real-time control.
Physical
  • Height: 1.5″
  • Width: 17″ (43.2 cm) or 19″ (48.3 cm) with rackmount option Depth: 14″
  • Weight: 9lbs.
  • Shipping Weight: 13 lbs.
Input power 100-240 VAC, 47-63 Hz
Environmental Temperature: 0-40 degrees C; Humidity: 0-95% noncondensing.
