Thor Broadcast Maximus 4k Fly

4k USB and HDMI camera with ePTZ region of interest

Product Highlights

  • Sony 1/2.5 Exmor 4K CMOS sensor
  • Video Output support Max 4K@ 30fps; 1080p@ 60, 30, 15 fps
  • 130° Horizontal Angle of View in 4K, 1080p ePTZ with 68°HOV
  • USB 3.0 & HDMI Simultaneous Video Output
  • Built in microphone array with omnidirectional pickup (up to 25 feet)

The Thor Maximus4kFly is a 4K ePTZ camera with simultaneous USB 3.0 and HDMI output.

This minimal design and compact structure has Sony’s new generation of 1/2.5-inch 4K Exmor image sensor with a built-in ultra-wide-angle 130-degree autofocus lens. Easy to operate with the included remote control, USB 3.0 and HDMI dual interface simultaneous video output is available at up to 4K@30FPS, and 1080p video with 4X Digital zoom. The built-in high-fidelity microphone has a maximum pickup distance up to 25 feet. Built in features like low illumination, low latency, clear picture quality, and delicate video quality means you can be set up and running in no time without fussy software and difficult attachments.

The Maximus4kFly comes equipped with an adjustable monitor bracket, or use the ¼-20 threaded mount to the included tabletop tripod or speaker stand adapter, or your favorite creative mount.

Integrate immediately and seamlessly into any video conferencing application that can use a webcam; without installing drivers. Thor Maximus4kFly uses standard USB UVC protocols already built into your operating system.

Unique for a “webcam” product, the Maximus4kFly can also be used in a hybrid or stand-alone POV camera role. Simply power by USB and use the HDMI output to bring the live video output to your switcher or other integrated video system.

There are no Technical Documents available at the moment.
Please call us at (800) 574-1702 for more information.
  • Oben Tabletop tripod
  • Speaker stand adapter (5/8 to ¼-20)
  • IR Remote
  • USB Cable
  • Power adapter

Thor Broadcast Maximus 4k Fly

Camera Video System  Sony 1/2.5″ CMOS, Effective Pixel 4k@3820*2160
Video Output Format 4k@30fps; 1920*1080P@60fps/50/30/25fps;1080I@60fps/50fps; 720p@60fps/50fps: 320*480
Lens 1 F=3,5mm FOV 110°
Lens 2 (Default) F=2,8mm FOV 130°
Auto Focus Support
Min Illumination 0,02Lux@F1,8, AGC ON
Shutter 1/30s ~ 1/10000s
White Balance Auto / Indoor / Outdoor / ONE PUSH, Manual
Camera Brackets Brackets with Damper Support ± 30° adjustment
Digital Noise Reduce 2D, 3D
BLC Support
WDR ON/OFF Support
USB Function Video Output 4K@30fps; 1920*1080p@60fps/50/30/25fps; 1080i@60fps/50fps; 720p
Encoding H.265 / H.264 / MJPEG
UVC Protocol Support
Video Communication UVC1.0-UVC1.5
Audio Function Built-in Microphone Yes
Audio Transmission USB 3.0
Voice Pickup Range 8 Meters
HDMI Interface Video Output 4k@30fps / 1920×1080@60fps/50/30/25 ; 108i@60fps/50/ ; 720p@60fps/50fps ; 320×480
Encoding H.265 / H.264 / MJPEG
Audio Output N/A
ePTZ Support, 4x Digital Zoom @ 1080P
Interface USB3.0 Type B Female (Compatible with all interfaces below USB 3.0 support video, control, power, supply, audio input, and output)
HDMI 2.0 (Compatible with HDMI 2.0, 1.4, 1.3A, 1.3 and other interfaces, only supports video transmission)
Generic Input Voltage 5V(USB 3.0)
Operation Temperature -10°C -+ 50c°C (14)
Storage Temperature -40°C ~ 60°
Power Consumption TBD
MTBF 50000 hours
