Product Highlights
- 4K@60Hz with RGB 4:4:4 color space, 18 Gbps bandwidth, HDR/Dolby Vision supported
- HDCP 2.2 and HDCP 1.4 compliant with cross conversion capabilities
- Pixel Accurate Reclocking
- No signal latency, zero frame delay
- Advanced EDID Management
Overview
The MX2-8×8-HDMI20 L is an HDMI 2.0 compatible standalone matrix switcher that supports uncompromised 4K UHD resolution at 60Hz 4:4:4 with up to 18 Gbps of available bandwidth.
The no-excuses performance with no signal latency comes in a compact size and silent design; and its crosspoint switching front panel keys make it particularly suitable for live events.
This standalone product has 8 HDMI 2.0 inputs and 8 HDMI 2.0 outputs transmitting up to 4K at 60Hz in 4:4:4 format, while supporting 3D, Dolby TrueHD and DTS-HD Master Audio.
The MX2-8×8-HDMI20-L matrix switcher supports both HDR and Dolby Vision in the HDMI signal.
Specifications
| Product name | MX2-8×8-HDMI20-L |
| Recommended application | Rental and staging |
| HDMI inputs | 8x |
| HDMI outputs | 8x |
| Audio inputs | No |
| Audio outputs | No |
| Front panel buttons | Yes |
| Front panel LCD menu | Yes |
| Connectors | |
| Power: | IEC standard, 110/220V |
| Video inputs: | 8 x HDMI 2.0 |
| Video outputs: | 8 x HDMI 2.0 |
| Audio inputs / outputs: | Stereo, balanced, 5-pole Phoenix |
| Serial control: | 3-pole Phoenix |
| Ethernet: | RJ45 |
| USB: | mini USB |
| Specifications | |
| Routing: | 8 input 8 output, non blocking architecture |
| Speed: | 18 Gbps per port |
| Resolution: | Up to 4096×2160@60Hz at RGB 4:4:4 (up to 600MHz pixel clock) |
| Dimensions: | 1RU height, 442 W x 277.5 D x 43,7 H mm* |
| Mounting: | Rack mountable, removable rack ears |
Technical Documentation
Lightware Visual Engineering MX2-8×8-HDMI20-L
8x8 HDMI 2.0 Matrix/Router
- Rentex No. LW8X8HDMI2
- Mfr No. 91310058
-
Available for same-day delivery in most major cities
-
Item is show-ready, double-tested for functionality
-
Accessories included, matched to the main unit
