Product Highlights

1-Channel Single Mode LC Fiber to 3G-SDI Receiver (FIDO-R-ST)
1-Channel 3G-SDI to Single Mode ST Fiber Transmitter, with SDI loop out (FIDO-T-ST)
Simplex connection (LC connector)
3G/HD/SD-SDI OUTPUT
Dual, matching SDI outputs (FIDO-R-ST)
Looping SDI output (FIDO-T-ST)
Supports pass-through of SDI metadata, including HDR
Uses 5-20VDC power (Universal power supply included)

Overview

FiDO-R offers unmatched flexibility and cost efficiency for SDI to Fiber conversion, allowing for long cable runs up to 10 km (32,808 ft) with electrical isolation – useful for eliminating ground loop problems. FiDO converters use a compact, low profile enclosure that works well in tight spaces around and behind equipment racks, trucks and on camera.

FiDO-T-ST offers unmatched flexibility and cost efficiency for SDI to Fiber conversion, allowing for long cable runs up to 10 km (32,808 ft) with electrical isolation – useful for eliminating ground loop problems. FiDO converters use a compact, low-profile enclosure that works well in tight spaces around and behind equipment racks, trucks and on camera.

Specifications

FIDO-R-ST Spec	Value
Video Formats	150 Mbps-3 Gbps, format agnostic
Video Input Digital	1-channel Single Mode LC Fiber Input, SMPTE-297
Nominal Wavelength	1260 – 1620 nm
Optical Sensitivity	-18dBm (Max)
Overload Power	-3dBm (Min)
Video Output Digital	1-channel Dual matching 3G-SDI BNC Outputs, SMPTE-259/292/424
Reclocking	270 Mbps, 1.483 Gbps, 1.485 Gbps, 2.966 Gbps, 2.970 Gbps – Auto Select – All other rates are passed through and not reclocked
Size (w x d x h)	4.6" x 1.71" x 0.85" (117.0 x 43.5 x 21.6mm)
Weight	0.5 lb (0.3 kg)
Power	2 watts, max. Uses 5-20VDC power, universal power supply included
Safe Operating Temperature	0 to 40 C (32 to 104 F)
Safe Storage Temperature (Power OFF)	-40 to 60 C (-40 to 140 F)
Operating Relative Humidity	10-90% noncondensing
Operating Altitude	<3,000 meters (<10,000 feet)
