Analog Way Pulse PLS300

Dual-Scaler Hi-Resolution Mixer Seamless Switcher

Analog Way

Product Highlights

  • Seamless transitions between ANY source
  • Dual Scaler
  • 1 Live PIP on a Live Background with numerous effects
  • 10 inputs and power in a single rack unit
  • Versatile for any kind of Live Application or High-End Installation
Rentex No. SWPULSE300 | Mfr No. PLS-300

Pulse by Analog Way is a Dual Scaler Mixer Seamless Switcher with Universal Analog and Digital input/output and Full High Resolution Digital Processing. The Pulse offers up to 10 inputs including 2 fitted with digital DVI and 2 fitted with SDI. SDI is compatible with SD and HD T V formats so is DVI which offers computer formats in addition. With state of the art 100% digital processing, the Pulse outputs Digital and Analog Signals in DVI and VGA (RGBHV) simultaneously with a selection of many formats up to Computer 2K. Pulse provides a high image quality thanks to its true 10 bits SD/HD auto adaptive pixel by pixel 3D motion compensation processing, de-interlacing, auto 3:2 and 2:2 reverse pull down circuitry & processing and Frame follower.

  • (1) ANALOG WAY PULSE 300
  • (2) VGA(M) to 5-WIRE(BNC) BREAKOUT
  • (2) VGA(F) to DVI-I(M) ADAPTER
  • (2) DVI-I(M) to”Y” DVI-D(F)/VGA(F)
  • (1) MANUAL
  • (1) 10′ CAT 5 CABLE
Input Analog SD/ED/HDTV & Computer: HD15-F x4 HD/SD-SDI: BNC x2 DVI: DVI-D x2 Audio: 3.5mm Stereo Jack x4 Audio: 5-pin MCO connectors x2 RS-232: DB-9 x2 Ethernet: RJ45 x1
Output DVI Main: DVI-I Female x1 DVI Preview: DVI-I Female x1 RGB/YUV Main: HD-15 Female x1 RGB/YUV Preview: HD-15 Female x1 Audio: 5-pin MCO connector x1
Signal System NTSC/PAL/SECAM
  • Standby On/Off
  • Input, Layer direct access
  • Freeze/Black
  • Effect and preset selection
  • Graphic VFD screen with control knobs and buttons for Easy and fast access to menus and adjustments
Power Requirements 100-250VAC, 50/60 Hz
Power Consumption 100W
Dimensions (WxHxD) 19 x 1.74 x 13.8″ (48 x 4.4 x 35 cm)
Weight 11 lbs (4.5kg)
