Product Highlights
- WUXGA (1920×1200) | 10,000:1 Contrast Ratio
- 52.91lbs | 20.9 x 7.9 x 21.6″ (WxHxD)
- Power Supply: 120 V AC, 9.5 A, 60 Hz
- Lens Options: 0.36:1, 0.36:1 HD, 0.7:1 HD, 0.9-1.1:1 HD, 1.3-1.7:1 HD, 1.7 – 2.4:1 HD, 2.4 – 4.7:1 HD, 4.6 – 7.4:1 HD
The Panasonic PT-DZ10KU 3-Chip DLP Projector features a dual-lamp system that helps make its body compact, while providing a full 10,600 lumens of brightness in dual lamp mode. When in Lamp Relay Mode, the projector eliminates any interruptions if a lamp should fail, and enables 24/7 projection. The projector’s Dynamic Iris feature uses a scene-linking aperture mechanism to achieve a contrast ratio of 10,000:1 without lowering its brightness.
The wide adjustment range of the powered horizontal/vertical lens shift function can be easily adjusted with the remote control. The unit can also be rotated 360° vertically, to accommodate various installation conditions. The lens-centered design contributes to easy installation. High brightness, along with a contrast ratio of 10,000:1, helps produce bright, crisp, and sharp images.
- (1) PANASONIC PT-DZ10KU 10K DLP
- (1) DZ10KU CAGE Bridge/Pipe Adaptor
- (1) Panasonic Projector Remote 3 Chip
- (1) Projector USB Manual
- (1) 14 AWG 5-15P to RED C13 Power
- (1) (4) M8x40mm Screw, Washer, Nut Combo
Display System | 3-Chip 0.96″ / 24.38 mm DLP |
Native Resolution | WUXGA – 1920 x 1200 |
Supported Resolutions | VGA – 640 x 480
WUXGA resolution is supported only when the signals are compliant with VESA CVT-RB (Coordinated Video Timing-Reduced Blanking). |
Format | NTSCÂ 4.43 PALÂ 60, M, N SECAM |
HDTV Compatibility | 480p 576p 720p 720p 1080i 1080p |
Pixels | 6,912,000 |
Brightness | Normal Mode: 10600 Lumens |
Projection Angle | None |
Uniformity | 90% |
Offset | None |
Aspect Ratio | Native:Â 16:10 |
Contrast Ratio | 10000:1 |
Dynamic Contrast Ratio | None |
DLP Link 3D | Yes |
Color Range | None |
Scan | Horizontal:Â 15 – 100 kHz Vertical:Â 24 – 120 Hz |
Lens | |
Projection Size | 70 – 1000″ / 177.80 – 2540.00 cm |
Features | |
Keystone Correction | Vertical: ± 40° Horizontal: ± 15° |
Picture-in-Picture | Yes |
Ceiling Mountable | Yes |
Rear Screen Projection | Yes |
Projection Tilt Option | Yes |
Internal Memory | None |
Input/Output Connectors | |
Inputs/Outputs | 1x BNC Video (Input) 1x DVI-D Video (Input) 1x HDMI Audio/Video (Input) 5x BNC Component Video (Input) 1x 15-pin VGA Video (Input) 1x BNC Composite Video (Input) 2x 9-pin VGA Control (Input) 1x 9-pin VGA Control (Output) 1x M3 Control (Input) 1x M3 Control (Input) 1x Ethernet LAN (Input) |
Wireless LAN | None |
General | |
Lamp (Bulb) | 2x UHM |
Watts | Normal Mode: 355Â W |
Life | Bright Mode:Â 3500 Hours |
Fan Noise | Normal Mode:Â 43 dB Eco Mode:Â 37 dB
Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards. |
Maximum Pixel Clock | 162 MHz
compatible with non-interlaced signals only, dot clock: 25 to 162 MHz |
Remote Control | Yes |
Security | Cable Lock Slot Password Protection |
Languages | English French German Italian Japanese Korean Portuguese Russian Spanish Traditional Chinese |
Power Requirements | 120-240 VAC, 50/60 Hz |
Heat Dissipation | 3413 BTU (AC 0 to 120V) |
Power Consumption | Maximum:Â 925Â W Standby Mode:Â 6Â W |
Altitude | 0 – 8858′ (0 – 2699 m) |
Temperature | Operating 32 to 113°F (0 to 45°C) Humidity: 10 – 80%
The operating temperature range is 32 to 104°F (0 to 40°C) when the Fan Control is set to High Altitude Mode (for altitudes from 4,593 to 8,858′ (1,400 to 2,700 m) above sea level). |
Dimensions (WxHxD) | 20.9 x 7.9 x 21.6″Â /Â 530.0 x 200.0 x 548.5 mm Lens Not Included
Height 200 mm with legs at the shortest position. |
Weight | 52.91 lb / 24.00 kg |
