Fujinon HD Lens XA55x9.5BESM

9.5-525mm f/1.7-2.9 2/3" EFP Box Lens with Lens Support

Fujinon

Product Highlights

  • 9.5-525mm 55x Zoom Lens
  • Versatile Wide-Angle to Tele Coverage
  • Optical Stabilization (OS) Technology
  • Anti-Fogging Design
Rentex No. SPLH100 | Mfr No. XA55X9.5BESM-S5L

The Fujinon 9.5-525mm f/1.7-2.9 2/3″ Bayonet EFP Box Lens is a high zoom ratio lens that lends itself to covering sporting events and other large-scale productions. Its 55x zoom range can extend from normal to super-telephoto focal lengths. The 2x Extender doubles your focal length to achieve tighter framing on your subject.

The box housing is specially designed to prevent fogging of the lens elements during changes in temperature or humidity allowing the lens to be used outdoors in inclement weather conditions. In addition to being weather sealed, this lens is secured against dust and other small particles that might harm the lens.

Since the lens incorporates Fujinon’s DigiPower Digital Servo technology, it can provide precise, repeatable digital control from studio paint boxes, PC’s, and traditional analog controls. Digipower also permits setting custom speeds for zoom and focus, zoom limiting, and other servo parameters. Diagnostics and advanced controls can also be accessed via an RS-232 port.

There are no Technical Documents available at the moment.
Please call us at (800) 574-1702 for more information.

Focal Length Without 2x Extender 9.5 – 525 mm With 2x Extender 19 – 1050 mm
Maximum Aperture f/1.7 (T1.85) @ 9.5 – 307mm f/2.9 (T3.61) @ 525mm
Zoom Range 55x
Minimum Object Distance (M.O.D.) 12.8′ / 3.9 m from image plane 9.8′ / 3.0 m from front of lens
Object Dimensions at M.O.D. (16:9) Without 2x Extender 9.1 x 5.1′ / 2782 x 1564 mm @ 9.5 mm 2 x 1.1″ / 51 x 29 mm @ 525 mm With 2x Extender 4.6 x 2.6′ / 1406 x 790 mm @ 19 mm 1 x 0.6″ / 26 x 15 mm @ 1050 mm
Angular Field of View (16:9) Without 2x Extender 53°34′ x 31°34′ @ 9.5 mm 1°03′ x 0°35′ @ 525 mm With 2x Extender 28°20′ x 16°09′ @ 19 mm 0°32′ x 0°18′ @ 1050 mm
Environmental RoHS Compliant
Dimensions (H x W x L) 10 x 10 x 34.4″ / 253 x 253 x 876 mm
Weight 55 lb / 25 kg
