Product Highlights
- 1-400A 3P Main Breaker
- Pass through camlock access with safety covers
- On Board monitoring of voltage and power draw
- 2 X 19 Pin Outlet 120V. (Parallel with 208V.19 pin)
- 2 X 19 Pin Outlet 208V. (Parallel with 120V.19 pin)
Overview
Suitable for a wide range of high-power applications, the Indu Electric 400A Power Distro is specifically designed to meet the needs of the LED market and can be integrated seamlessly with smaller distros. Its hydraulic magnetic breakers are 100% load rated, ensuring continuous use at full rated output without compromise.
Specifications
| Input Type |
| 5x Camlock |
| 3x LED |
| 5x Camlock pass thru |
| 1x Main Breaker 300A/3P |
| LED Stripe + Switch |
| 1x Dig. Meter |
| Branch Devices |
| 2x L21-30 |
| 2x 19 Pin Outlet 208V |
| 2x 19 Pin Outlet 120V |
| 6x 5-20 |
| 3x Powercon True 1 |
| Protection |
| 2x Breaker 30A/3P |
| 12x Breaker 20A/2P |
| parallel to 208V outlets |
| 6x Breaker 20A/1P |
| 3x Breaker 20A/2P |
| Dimensions |
| LxHxW: 24″ x 28″ x 24″ |
| Rating |
| Rated Voltage: 120/208V-30 4P/5W |
| Rated Current: 300A/50/60Hz |
| Nema 1 Dry Locations |
Technical Documentation
Indu Electric 400A Power Distro
With (2)120/208v Soca
- Rentex No. TP2
- Mfr No. CB1-5WPT-12x520
-
Available for same-day delivery in most major cities
-
Item is show-ready, double-tested for functionality
-
Accessories included, matched to the main unit
